asserted by the Drive, the Host asserts -DMACK while it is ready to transfer data by DMA and asserts -IOWR once
for each 16 bit word to be transferred from the Host.
Interrupts are not generated on every sector, but upon completion of the transfer of the entire number of
sectors to be transferred or upon the occurrence of an unrecoverable error. At command completion, the
Command Block Registers contain the cylinder, head and sector number of the last sector written. If an error
occurs, the write terminates at the sector where the error occurred. The Command Block Registers contain the
cylinder, head, and sector number of the sector where the error occurred. The amount of data transferred is
indeterminate.
When a Write DMA command is received by the Drive and 8 bit transfer mode has been enabled by the Set
Features command, the Drive shall return the Aborted error.
Table 65: Write DMA
Task File Register
7
6
5
4
3
2
1
0
COMMAND
CAh or CBh
DRIVE/HEAD
CYLINDER HI
CYLINDER LOW
SECTOR NUM
SECTOR COUNT
FEATURES
LBA
D
Cylinder High (LBA23:16)
Cylinder Low (LBA15:8)
Sector number (LBA7:0)
Sector Count
nu
Head (LBA 27:24)
6.43 Write DMA Ext (35h) 48bit LBA
This command uses DMA mode to write from 1 to 65536 sectors as specified in the Sector Count Register. A sector
count of 0 requests 65536 sectors. The transfer begins at the sector specified in the Sector Number Register.
When this command is issued the CompactFlash TM Storage Card sets BSY, puts all or part of the sector of data in
the buffer. The Card is then permitted, although not required, to set DRQ, clear BSY. The Card asserts DMARQ
while data is available to be transferred. The host then writes the (512 * sector-count) bytes of data to the Card
using the DMA protocol. While DMARQ is asserted by the Card, the Host asserts -DMACK while it is ready to
transfer data by DMA and asserts -IOWR once for each 16 bit word to be transferred from the Host.
Interrupts are not generated on every sector, but upon completion of the transfer of the entire number of
sectors to be transferred or upon the occurrence of an unrecoverable error.
At command completion, the Command Block Registers contain the LBA of the last sector written. If an error
occurs, the write terminates at the sector where the error occurred. The Command Block Registers contain the
LBA of the sector where the error occurred. The amount of data transferred is indeterminate.
When a Write DMA command is received by the Card and 8 bit transfer mode has been enabled by the Set
Features command, the Card shall return the Aborted error.
Table 66: Write DMA Ext
register write
previous
current
Task File Register
15:8
7
6
5
4
3
2
1
0
COMMAND
-
35h
DRIVE/HEAD
-
1
1
1
Drive
Reserved
LBA High
LBA Mid
LBA Low
SECTOR COUNT
FEATURES
LBA (47:40)
LBA (39:32)
LBA (31:24)
15:8
nu
LBA (23:16)
LBA (15:8)
LBA (7:0)
7:0
nu
6.44 Write FPDMA Queued (61h) (if NCQ feature set supported)
This command is mandatory for devices implementing the NCQ feature set (see feature set reference).
This command causes data to be transferred from the host to the device.
When the Forced Unit Access (FUA) bit is set to one regardless of whether volatile and/or non-volatile write
caching in the device is enabled or not, the user data shall be written to non-volatile media before command
completion is reported. When the FUA bit is cleared to zero the device may return command completion before
the data is written to the media.
Swissbit AG
Industriestrasse 4
Swissbit reserves the right to change products or specifications without notice.
Revision: 0.92
CH-9552 Bronschhofen
Switzerland
F-240_data_sheet_CA-HxBV_Rev092.doc
Page 40 of 56
